Fixed Mount Barcode Scanner

The BR13WT2IN is a high-performance barcode scanning module. It excels at reading a wide range of challenging 2D and 1D barcodes, including damaged barcodes, DPM (Direct Part Marking) engraved codes, highly reflective barcodes, high-density barcodes, small-sized barcodes, and screen barcodes. The module supports HID, VCOM, RS232, and optional ethernet communication interfaces, making it ideal for embedded systems and automated control systems.

A fixed-mounted barcode scanner is a stationary device that enables hands-free, high-speed, and high-volume scanning of barcodes. It is installed at once at a fixed position. It does not require any user to manually aim and trigger the scan, unlike handheld scanners. It is designed to read the barcode automatically without any user intervention. Fixed mount barcodes scan the items on a conveyor belt or at a point-of-sale terminal when they pass by them.

How the Fixed Mound Barcode Scanner Works?

A fixed-mounted barcode scanner operates on various technologies, where the most common are laser and image-based systems. Let’s know more about its working:

• Laser Scanner: It uses a laser beam to measure the amount of light reflected by the black and white bars that scan across the barcode. Then it converts this data into a digital signal. Laser scanners are very efficient for reading 1D barcodes from a distance.
• Imager Scanner: It is used to capture a two-dimensional image of the barcode, where the image scanner works as a digital camera. Then, with the help of a decoding algorithm, an image scanner identifies and interprets the barcode’s data. They are capable of reading both 1D and 2D barcodes, even from various angles. It can even read the code if it is damaged or poorly printed.

What are the advantages of using a Fixed Mount Barcode Scanner?

• Increased efficiency and productivity: The fixed-mount barcode scanner does not require any manual intervention; it can operate the scanning process automatically. This ensures high efficiency and a low rate of mistakes, along with rapid operation.
• High Accuracy: As there is no need for a human to operate it, it minimizes human error and provides precise accuracy. It offers near-perfect data accuracy, reducing mistakes in inventory tracking and other critical tasks.
• Durability: The fixed mounts are designed with high durability, as this device is installed permanently in a fixed position. Thus, they are built with rugged enclosures so that they can handle a harsh industrial environment effectively.
• Hands-Free Operation: As it operates automatically, it allows the workers to focus on other tasks. This saves their time, along with improved workflow and reduced repetitive strain injuries.

Industrial Application of Fixed Mount Barcode Scanner in the UAE

In the vibrant and rapidly growing economy of the UAE, fixed-mount barcode scanners are an important part of automation and supply chain optimization in multiple sectors. The fixed mount barcode scanner is the foundation and technology for data capture and real-time inventory management.

• Manufacturing and Automotive
  Work-in-progress (WIP) Tracking: When the product moves along the assembly line, a fixed-mount barcode scanner reads the barcode present on each component or sub-assembly automatically. It helps to track the real-time record of the manufacturing process, which ensures traceability and quality control.
  Direct Part Marking (DPM): In the automotive and aerospace industries, barcodes are engraved or laser-marked directly onto the parts. In this event, rugged fixed-mount images are used to read these marks, which ensures every component can be tracked even in challenging conditions across the entire production life.
• Logistics and Warehousing
  Conveyor Systems: A common practice where the scanners are integrated into automated conveyor systems. It automatically identifies and sorts the packages or pallets that move at high speeds.
  Shipping and Receiving: A fixed scanner can quickly read the incoming and outgoing shipments at loading docks. It allows automated inventory updates and verification against bills of lading.
• Retail and E-commerce
  High-Volume Point-of-Sale (POS): In the UAE’s supermarket and high-traffic retail stores, fixed-mount scanners are used at the checkout counters. This allows cashiers to scan items, which reduces the customer wait times.
  Self-Service Kiosks: They can be used at heavily trafficked public places where there is a chance of a kiosk, such as airports, cinemas, or retail stores. The fixed-mount barcode scanner helps to scan the boarding pass, ticket validation, and automated payments.
• Food & Beverage
  Packaging and Bottling Lines: Fixed-mount scanners are used to track the products by scanning their batch codes. It also scans expiry dates and serial numbers to ensure product quality and regulatory standards.
  Traceability: This scanner helps to track the supply chain and record each detail, such as where it comes from, how it is processed, where it is stored, and how it is delivered. This information is essential as it may be required for product recall, checking quality, or even if it needs to follow international standards.
• Pharmaceuticals and Healthcare
  Traceability and Anti-counterfeiting: As the UAE government has strict regulations on pharmaceuticals, tracking is required. It helps the pharmacy companies to read 2D barcodes on medicine packaging to ensure product authenticity. It is used in production lines and at pharmacies.
  Sample Tracking: In laboratories and hospitals, these scanners are used to track blood samples, test tubes, and medical equipment. This prevents human error and ensures accurate recordkeeping.

Specification

· Excellent scanning sensitivity and decoding capability
· 1.3-megapixel resolution
· Capable of scanning barcodes displayed on screens
· Supports external trigger scanning and autosensing scanning
· Supports dual non-isolated output control

Application

· Embedded in commercial, industrial, and medical equipment
· Industrial fixed-mount scanning
· Product sorting and barcode scanning
· Other scenarios requiring high scanning performance or intensive scanning operations

Frequently Asked Questions about Fixed Mount Barcode Scanner

Question 1. What are the main types of scanning technologies?

Answer. The main types of scanning technology include the following:

• Laser scanners
• Imaging scanners
• Omnidirectional scanners

Question 2. What are the advantages of using a fixed-mount scanner?

Answer. Some common advantages include high efficiency and speed, enhanced accuracy, hands-free operation, superior durability, versatility, long-term cost-effectiveness, and more.

Question 3. What are the applications for fixed-mount scanners?

Answer. Some of the applications of fixed fixed-mount scanner include:

• Retail
• Manufacturing
• Logistics and Warehousing
• Healthcare
• Transportation

Question 4. How do I choose the right fixed mount scanner?

Answer. When choosing the right fixed mount scanner you should consider scanning capabilities, speed and volume, durability and environment, connectivity and integration.
